PCK210型智能半自動開口閃點測定儀
本儀器用于測定石油產品開口閃點值。中液晶觸摸式鍵盤、向?qū)讲藛慰呻S意調節升溫速率.
執行標準 ： GB/T3536-2021
儀器特點 ：
便攜式壓縮機體，封閉防塵式機芯，電纜走線；
配有智能時鐘顯示；
自動修正大氣壓強的影響并計算修正值；
掃描、檢測、風冷自動完成。
100次試驗結果記錄可查詢
技術參數 ：
測量范圍 ： 室溫～400℃
分 辯 率 ： 0.2℃
驗 火 源 ： 石油液化氣/或丁烷氣體
量重復性 ： ≤4℃
量再現性 ： ≤6℃
使用環境 ：（環境溫度）10～30℃（相對濕度）小于80%RH
功 率 ： 600W
電源電壓 ： AC220V±10%
頻 率 ： 50Hz±5%
外觀尺寸 ： 380mm*330mm*300mm
重 量 ： 15kg
PCK210intelligent opening flash point tester
This instrument is used to determine the petroleum products open flash point value. , Operator interface, color LCD touch keyboard, wizard-driven menus adjustable heating rate, in print in English, (optional) 232 computer management interface, the Model instrument as the company exports instrument.
Executive Standard: GB/T3536-2008
Instrument features:
Portable compressor body, closed dust movement, cable routing;
Warming with the experimental curve function of time;
With intelligent clock display;
Automatically corrected atmospheric effects and to calculate the correction value;
Done automatically scan, ignition, detection, air-cooled.
44mm paper dot matrix printer, and print the results can be stored for long periods
100 test results are recorded inquiries and print
Independent Fp workstation (optional)
Technical parameters:
Measuring range: room temperature to 400 ° C
Distinguish: 0.2 ℃
Experience fire source: liquefied petroleum gas and / or butane gas
Amount of repeatability: ≤ 4 ℃
Cover reproducibility: ≤ 6 ° C
The use of the environment: ambient temperature 10 to 30 ° C (relative humidity) is less than 80% RH
Power: 600W
Power supply voltage: AC220V ± 10%
Frequency: 50Hz ± 5%
Dimensions: 380mm * 330mm * 300mm
Weight: 15kg |
